Lunt LS50F Hydrogen-Alpha Front-Mounted Etalon System w/ B1200 Blocking Filter
To measure for your adapter plate take a measurement of the outside diameter of the dew shield on your refractor telescope. If measuring in inches, multiply the measurement by 25.4 to find your measurement in millimeters.
The LS50F offers more aperture for brighter views and finer detail, using the same center-supported etalon design as the LS40F. At 50mm, the increased light grasp enhances both visual observing and imaging potential while maintaining a <0.65 angstrom bandpass.
Tilt tuning keeps operation straightforward—angle the housing to center the H-alpha line and you're observing. No pressure systems, no external controls.
The LS50F includes a B1200 blocking filter (6mm clear aperture, for focal lengths up to 540mm) and a custom adapter plate. Provide your objective cell diameter at checkout and we'll machine the adapter to fit—at no additional cost for objective housings up to 4 inches.
Remove the system in seconds to return your refractor to nighttime duty.
Technical Note: This system is designed with a center-mounted foot to support the etalon. Consequently, the filter is center-obstructed.
Features:
-
50mm etalon with center-supported design (Note: Filter is center-obstructed)
-
<0.65 angstrom bandpass (H-alpha, 656.28nm)
-
Tilt-tuned wavelength control
-
B1200 blocking filter included (6mm CA, up to 540mm FL)
-
Custom adapter plate included (up to 4" objective cells—specify diameter at checkout)
-
Visual and imaging capable
What's Included:
✓ Lunt LS50F Hydrogen-Alpha Front-Mounted Etalon System
✓ B1200 Blocking Filter
✓ Custom Adapter Plate
Specifications:
|
Etalon Diameter |
50mm |
|
Etalon Design |
Center-supported (center-obstructed) |
|
Bandpass |
<0.65 Å |
|
Wavelength |
H-alpha (656.28 nm) |
|
Tuning Method |
Tilt-tuned |
|
Blocking Filter |
B1200 included |
|
Blocking Filter Clear Aperture |
6mm |
|
Maximum Focal Length |
Up to 540mm |
|
Adapter Plate |
Custom-machined, included |
|
Compatible Objective Cells |
Up to 4" diameter (specify at checkout) |
|
Observing Modes |
Visual and imaging |
|
Mounting |
Front-mounted, quick removal |
