LW Scientific i4 Trinocular Microscope - with 4 Infinity Semi-Plan Objective - Model # I4M-TN4A-ISL3
The i4 Trinocular Microscope with 4 Infinity Semi-Plan Objective is designed for professionals who require exceptional optical performance, versatility, and long-term reliability.
Built with Semi-Plan optics, this microscope delivers sharp, high-contrast imaging, ensuring accurate results for laboratory diagnostics, research, and clinical applications.
Equipped with a 30° inclined, 360° rotating head, the i4 microscope supports ergonomic viewing comfort for users during extended sessions.
Its 30-year anti-fungal coating preserves lens clarity, while cool, long-lasting LED illumination ensures consistent, high-quality lighting without overheating.
Ideal Applications:
- Laboratory
- Research
- Clinical Applications
Features:
-
Infinity Semi-Plan Optics – Delivers sharp, distortion-free images for detailed analysis.
-
Adjustable Rotating Head – Accommodates taller users for a comfortable viewing experience.
-
30-Year Anti-Fungal Lens Coating – Protects against fungal growth to maintain optical clarity.
-
Energy-Efficient LED Illumination – Provides bright, cool lighting with an extended lifespan.
-
Durable & Cost-Effective – High-quality performance at an affordable price for clinics, labs, and research facilities.
Why Choose the i4 Infinity Microscope?
-
Precision Imaging: Ideal for clinical, veterinary, and research labs needing reliable optical performance.
-
User-Friendly Design: Ergonomic trinocular viewing head with 30° inclined, 360° rotation for comfortable use during extended viewing sessions.
-
Long-Term Investment: Anti-fungal lens protection and LED illumination increase durability and reduce maintenance costs.
Head:
-
Trinocular
-
Digital cameras and adapters available
-
Diopter adjustment
-
Inclined 30°, rotates 360°
-
10X/18 WF Eyepieces (Optional 10X/20X Super WF HP)
-
Interpupillary distance range 48-75mm
Nosepiece:
-
Reverse quadruple nosepiece
-
Multiple ball bearing mounted
Objectives:
-
Infinity Semi-Plan Objectives
-
4X, 10X, 40XR, 100XR (oil immersion)
-
Optional 50X (Oil) Objective
-
Anti-fungal, parfocal, parcentric, color-coded
Stage:
-
Mechanical stage (133mm x 143mm)
-
Coaxial drive controls, metal rack & pinion
-
Range of traverse: 78mm x 50mm
-
Stage locking lever
-
Slow-close hydraulic slide finger
Focus:
-
Coarse adjustment: range of 15mm
-
Fine adjustment: graduation of 2µm
-
Tension control knob
Illumination:
-
Moveable Abbe condenser, NA 1.25
-
Iris Diaphragm
-
LED "daylight" long-life light source
-
Variable light adjustment
-
100-240V 50-60Hz automatic-switching electronics
-
3-prong LJL-listed power cord
Option
-
Phase contrast, 50x oil objective, camera attachments, eyepiece pointer, and more.
What's Included:
✓ LW Scientific i4 Trinocular Microscope with 4 Infinity Semi-Plan Objective
✓ Instructional Manual
Specifications:
| Height: | 14.1" (352.5 mm) |
| Length: | 10.7" (267.5 mm) |
| Width: | 6.1" (152.5 mm) |
| Weight: | 16.6 lbs. (7.53 kg) |
Product Manual & Spec Sheet:
Download the LW Scientific i4 Trinocular Microscope - I4M-TN4A-ISL3 Product Manual & Spec Sheet
